TMREC-FHD RECORD MASTER
Model No.:
TMREC-FHD
JAN:
4533239032314
| Model Number | TMREC-FHD |
| JAN Code | 4533239032314 |
| Input Resolution | 1920×1080 (60p/50p/30p/25p/24p/50i/60i) 1280×720 (60p/50p) 720×480 (60i/p), 720×576 (50i/p) |
| Output Resolution | Maximum 1920×1080, 1280×720（60p）pass-through |
| Recording Resolution | Main body recording resolution: 1920×1080 (60p), 1280×720 (60p), 720×480 (60p) Recording resolution in PC mode: 1920×1080 (30p), 1280×720 (60p) |
| Output Format | MP4 (H.264) |
| Composite Input | NTSC, PAL ※Dedicated Cable Included |
| Input Interface | HDMI, AV, MIC (4 Polar CTIA Earphone Microphone), USB |
| Output Interface | HDMI, micro USB (PC), earphone, speaker |
| Supported File Systems | FAT32, FAT |
| Supported Capacity | Up to 4GB per file |
| Bit Rate | Maximum: 30Mbps |
| Supported Storage Capacity (Maximum) | HDD: 4TB USB Flash Drive: 128GB SD Card: 128GB |
| Weight | 300g |
| Power Supply | DC 5V, 2A |
| Package Contents | TMREC-FHD main unit, instruction manual and warranty card, dedicated remote control, HDMI cable, AV connection cable, USB power cable and USB power adapter |
Firmware Update Procedure:
Important Notice:
Please charge the main unit battery up to 80% before updating. Also, please make a copy of the recorded files, etc., beforehand to prepare for the possibility of file loss. The data and file loss caused by the update operation is not covered by any guarantee.
This update is only possible on Windows OS.
Update procedure:
1. Download the latest version of the firmware from the "Latest firmware download" at the bottom of the product page, and after extracting it to the desktop, copy the firmware file stored to the root folder of the SD card (the top-most hierarchy).
2. Copy the extracted .img file to a USB memory or SD card.
3. Connect the USB memory or SD card with the firmware to the TMREC-FHD/TMREC-4KS/TMREC-4KMAX, turn off the power, and restart it.
4. The firmware update confirmation will be displayed automatically, and the update will start automatically by confirming, so please wait until it is completed.
→ The firmware update will be completed automatically and the device will restart with the new firmware version.
